Tilting cylinder hydraulic cylinder telescopic cylinder 700mm 5t

The photos and illustrations show only the external appearance of the cylinder. The main elements that affect the quality and proper operation of the actuator for a long time are hidden inside (reinforced seals, stuffing box, piston rod and high-quality pipes). All our actuators ensure the highest quality of these elements. If you choose a product from our range, you are making a good and smart choice - not a Chinese import! Cylinders with a load capacity of up to 5 tons, mounted in trailers, vans and special vehicles. Due to its design, it is used in tipping trailers with 3-way tipping (rear and side). The hydraulic cylinder is perfect for hydraulically driven machines and devices. It can be used in agriculture, horticulture, forestry and construction. Telescopic cylinders consist of several segments that can be extended one behind the other - chrome-plated cylinder liners. This allows the cylinder to expand significantly when folded compared to its overall length. Telescopes are single-acting actuators. The stroke is started by supplying hydraulic oil under pressure. The return of the actuator is caused by the action of the distributor, which relieves the pressure from the system - the drop occurs by gravity, most often under the influence of the weight of the cargo box. To avoid damage to the sleeve guard due to excessive thrust at the actuator's maximum stroke, a safety device (rope, hydraulic or electric shut-off valve) should be used. A well-tuned actuator in the middle of the structure ensures a tilt angle of the structure between 40 and 45 degrees. Depending on the type of cargo, you can choose this angle yourself - the following table may be helpful (see gallery) (TABLE OF REQUIRED STROKE TO TILT THE TRAILER TO THE REQUIRED ANGLE °) DP - Distance between cylinder bracket and trailer hinges in [mm] (DP = 1/2 S) a ° - Tilt angle of the trailer body C - Drive stroke in mm S = DP * 2 Technical data 3-stage actuator The actuator is mounted on the fastening bolt with a 40 mm diameter. Length of the folded cylinder: 395 mm Piston stroke: 700 mm The total length of the actuator when unfolded: 1095 mm Actuator diameter: 95 mm Output: M22x1.5 Speed max. Piston rod: 0.5 m/s Output pressure: 0.5 MPa Maximum working pressure: 160bar Oil consumption: 2.5 l Permissible ambient temperature -40 to +60 ℃ Permissible oil temperature -15 to + 80 ℃ Screw connection type: Threaded, screwed into the pipe Piston rod: chrome-plated Fluid type: Mineral oil-based hydraulic oil Ball socket with a diameter of 45 mm The socket has 4 holes 11 mm Seat height 43 mm Hole spacing 69 mm Secured by two shells and a separating ring. The holder is solidly built, the cylinder seat is reinforced, the cylinder protection is screwed on with hexagon socket screws. By using a console with an actuator, the trailer can be tilted to three sides.
