Inel N-10R tubular motor 13 Nm YYGL35R 13/14 external roller shutters roller shutters
Card 1-3 · Advance 3-5 business days
Final price plus shipping according to § 19 UStG without VAT ID
Product information
N-10R tubular motor 13 Nm YYGL35R 13/14 N-10R tubular motor 10 Nm 230 V with built-in radio control
The engine torque is 13 Nm at 14 rpm. It is adapted to the octagon tube with a diameter of 40mm. Works with the following remote controls: PIL02/04XB ARROW-01PT PFEIL-01/04NS ARROW-01.05.09.19 PIL-19/99PMT PFEIL-01/05/09/19DL PIL-19/99DLT PIL-19/99MMT. The set contains the necessary accessories. The motor has protection against damage caused by overheating - the motor switches off automatically after 4 minutes of continuous operation.
Technical data
Torque (Nm) 13 Speed (rpm): 14 Pipe diameter (mm): 35 Supply voltage (V): 230 Mains frequency (Hz): 50 Power (W): 126 Current (A): 0.56 Working time (min): >=4 Sealing class (IP): IP44 Weight (kg) 1.9 Length L1/L2 (mm): 555/390 Set contains:Login
4 reviews
24 June 2026 09:13
Wie erwartet
Inel N-10R Rohrmotor passt, Einbau unkompliziert.
21 June 2024 15:07
Okay
War das richtige Teil, alles okay.
6 July 2022 09:25
Macht seinen Job
Für den Preis in Ordnung, Versand normal.
3 July 2020 19:47
Keine Beanstandung
Bestellt, geliefert – Inel N-10R Rohrmotor läuft.
Reviews are checked by our team and only published after approval — to keep quality and trust for all customers.
Technical data
- Item number
- HT-14947
- Brand
- Inel
- Weight
- 8 kg
