4-piece hydraulic set 40 l/min for TURA with swimming part and lock for TURA swimming

Technical data

Composition of the kit Ball joystick with 2 buttons 2x Bowden cable 2-part hydraulic distributor 40 l/min - floating part + latch 2x solenoid valve - distributor 6/2 12V 50L/min The set is perfect for hydraulically driven machines and devices. It ensures effective control of two sections on TUR front loaders (frame height and bucket inclination) and two additional sections at the touch of a button. The set offers many advantages that affect the dynamic, fast and safe control of the machine. It can be used in agriculture, horticulture, forestry and construction. It is suitable for use in: agricultural machinery, tractors, sprayers, cyclops, HDS loaders, construction machinery, loaders, excavators, sweepers, industrial machinery and others. High-quality monoblock distributor in parallel arrangement with floating (absorbing) chamber. It features a compact design, stable operation and high versatility. This allows you to control two double-acting or (after closing one of the connections) single-acting drives. A series connection to the existing system is possible (pressure sleeve required). Control from the cab with cables and joystick.!ATTENTION! In a particular manifold, the section with a lock is only in a section with a FLOATING FUNCTION. The universal distributor is used in various types of machines, such as: Cyclopie Tury Loaders Plows Forklifts and many more Three-stage slider (1 – 0 – 2) with lock with lock, i.e. h. h. it holds the position independently in the working position Position 0 Neutral (joystick is vertical - the cable is loose) the piston rod of the actuator is stationary - the oil flows to the overflow. Working position 1 (joystick diagonally forward) The piston rod of the cylinder extends. Working position 2 (joystick tilted backwards) The cylinder piston rod retracts. Three-stage slider (1 - 0 - 2) jumps back to position 0 by itself. Neutral (joystick is vertical - the cable is loose) the piston rod of the actuator is stationary - the oil flows to the overflow. Working position 1 (joystick diagonally forward) The piston rod of the cylinder extends. Working position 2 (joystick tilted backwards) The cylinder piston rod retracts. Connection: Power (P) BSP 1/2'' Return (T) BSP 1/2'' Output for 3/8'' BSP sections Connection 1/2" BSP Technical

Specifications

Oil flow 0 - 40 l/min Maximum working pressure: 250 bar Permissible ambient temperature: -40 ℃ to +60 ℃ Permissible oil temperature: -15 ℃ to +80 ℃ Equipped with a safety valve. This solenoid valve is an ideal solution when the hydraulic distributor used (to control the actuator) does not have an additional section to control another actuator, most commonly with a 2-piece distributor, such as: E.g., a gripper, a crocodile, etc. (electrical pulse through the “P” key), we can control two independent double-acting actuators, d ℃ Allowable oil temperature: -15 ℃ to +80 ℃
