25x Fischer anchor 12x120 M12 anchor dowels for CONCRETE LE12120_25U
Card 1-3 · Advance 3-5 business days
Final price plus shipping according to § 19 UStG without VAT ID
Product information
- Serie / Lizenz
- Fischer
- Versandgewicht
- 8,00 kg
- Artikelnummer
- HT-15726
Fischer steel ring bolt anchor (Express) – heavy duty FWA 12 x 120 M12 The price is for – 1 pack – 25 pieces. Material: Bolt, ring and nut made of galvanized steel Technical data / installation parameters Diameter of the mounting hole: 12 mm Recommended loads [kN] Elongation - 3.2 kN / 4.8 kN / 5.8 kN Shear - 3.2 kN / 4.8 kN / 5.8 kN Recommended bending moment - 13.2 Nm Dimensions of the components Minimum edge distance - 60 mm / 75 mm / 90 mm Minimum center distance - 120 mm / 150 mm / 180 mm The minimum thickness of the substrate is 100 mm / 100 mm / 120 mm The diameter of the hole in the element is 14 mm Substrate: C20/25 concrete, cracked concrete (NOTE - lower strength parameters) Application for the assembly of: balustrades, handrails, gates, steel profiles, frames, wooden slats, system profiles, cast connections,
Login
5 reviews
27 June 2026 16:56
Wie erwartet
Wie beschrieben angekommen.
26 September 2025 19:59
Passt so
Die Bestellung passt, Qualität normal.
21 November 2024 17:45
Keine Beanstandung
Für das Projekt ausreichend.
21 January 2024 15:19
Wie erwartet
Wie beschrieben angekommen.
29 March 2023 09:13
Schnell da
Unaufgeregt okay, tut was es soll.
Reviews are checked by our team and only published after approval — to keep quality and trust for all customers.
Technical data
- Item number
- HT-15726
- Brand
- Fischer
- Weight
- 8 kg
